High Voltage Electrified Products

Best-in-class electrified platforms for an emission-free future.

We have it all.

While the shift towards electrification is well under way, the real innovators are no longer those companies that are simply supplying eDrive products. Real innovation is awarded to those who are taking electrification to the next levels of efficiency and range. Magna is embracing this challenge and is consistently refining its electric drives. The goal: best-in-class (BIC) efficiency, safety, dynamics, and convenience.

As automakers continue to progress towards a zero-emissions future, we are the supplier partner that can give them new and innovative products to help them get there. Magna’s high voltage portfolio covers the entire range for pure electric vehicles, from single components to complete systems – from eAxles and eDrive transmissions up to highly integrated eDrives. Our eDrive platform approach provides the highest flexibility using cross-project synergies with maximum scalability from 50 – 250 kW, while our eDrive systems are qualified for 400V operation voltage and ready for 800V.

The automotive market also requires different levels of hybridization to cover global demands. Magna’s full and plug-in hybrid vehicle solutions take on these different tasks such as supporting acceleration via boosting, recuperation, or charging a battery – through to pure electric driving.

Magna offers a variety of tailored solutions for future green mobility, without compromising driving pleasure, performance, or safety. Whether providing vehicle expertise, full powertrain systems, or individual components with its EtelligentDrive powertrain solutions, Magna can supply these attributes for all electrified platforms – from mild to full and plug-in hybrids to purely battery electric vehicles.

Primary / Complementary Drive Units

Highly Integrated eDrive Low Highly Efficient

This highly efficient eDrive system is designed for both primary and secondary drive applications in the lower power range. It can be applied as a highly efficient secondary Drive to midsize EVs and Px4 PHEV’s, and as an efficient primary drive to small electric vehicles.

The highly integrated eDrive System contains a flexibly and best-in-class packaged induction e-motor, an integrated high voltage inverter with all integrated combined oil-/water-cooling, a layshaft gearbox and is designed coaxially. Park lock and decoupling are available as optional features. The advanced speed control interface enables Etelligent launch vehicle function.

Power range from 80 kW to 120 kW, scalable from 400V to 800V boardnet.

Download Factsheet

Secondary Drive Units

eBeam™

Heavy Duty electric drive for frame-based vehicle usage. Structure-oriented design to support high payload and towing capability with matching power for continuous duty usage, high peak torque and robustness.

Find out more about our Heavy Duty (eBeam™ & 3in1) family and download the Deep Dive contents:

Technical Paper - Magna's eBeam Technology: Uncompromising Pickup Truck and LCV Electrification

Electric Axle Drive System eBeam™ Mid

Structure oriented design to support high payload vehicles with matching power for continuous duty usage.

Trucks work hard, both for your family and at the job site. An electric truck has to be equally capable, and Magna’s eDS HV eBeam electric axle makes that possible. Innovative engineering means no compromises in towing, payload, or off-road capabilities, and no expensive re-engineering of the truck’s architecture. Magna’s eBeam uses the OEMs’ suspension and brake systems, and is scalable so that it can be used in any solid rear axle truck platform- including light commercial vehicles. Available in several variants, including: single motor/single speed, single motor/two speed, and a twin motor variant. Options include ePark Lock, electric locking differential, with power ranges up to 250kW per motor.

Download Factsheet

Electric Axle Drive System eBeam™ High

Structure oriented design to support high payload vehicles with matching power for continuous duty usage.

Trucks work hard, both for your family and at the job site. An electric truck has to be equally capable, and Magna’s eDS HV eBeam electric axle makes that possible. Innovative engineering means no compromises in towing, payload, or off-road capabilities, and no expensive re-engineering of the truck’s architecture. Magna’s eBeam uses the OEMs’ suspension and brake systems, and is scalable so that it can be used in any solid rear axle truck platform- including light commercial vehicles. Available in several variants, including: single motor/single speed, single motor/two speed, and a twin motor variant. Options include ePark Lock, electric locking differential, with power ranges up to 250kW per motor.

Download Factsheet

Dedicated Hybrid Drives

Highest flexibility for multiple applications

Usually in hybrid architectures, to enable boosting and recuperation, an e-machine must be added to the transmission or engine. However, this also leads to a critical cost-benefit question. With the new Dedicated Hybrid Drives (DHD) we simplified our existing hybrid concepts and utilized our long-term development experience with hybridized dual-clutch transmissions. We added a strong e-machine, shifted the dynamic operation towards it while standardizing the engine operation, and reduced the number of gears.

DHD offer best-in-class electrical performance and efficiency, outstanding convenience and adapt to real-world requirements in different vehicle segments and markets. Magna is looking at a complete systems approach to both conventional and electric platforms, so watch out for more DHD variants as they are developed.

Find out more about our DHD product family and download the Deep Dive contents:

Dedicated Hybrid Drive DHD Duo

The Dedicated Hybrid Drive DHD Duo is a two e-motor suitable for HEV applications, delivering outstanding performance with high drivability and comfort even when driving in congested traffic. DHD Duo is developed in a platform approach, scalable in power and in number of gears to meet B to E vehicle segment requirements.

It enables a flexible architecture switch between P1 + P3, P2 + P3 and Range Extender (REEV). Within the standard P1+P3 hybrid architecture. the P1 e-motor acts as a generator to start the ICE and charge the battery at any time. The P3 traction e-motor is responsible for all-electric starting and reversing and drives the front wheels in serial mode. In parallel mode, both ICE and traction e-motor will cope with each other to deliver as much torque to the wheels as possible to ensure strong acceleration. With this architecture, DHD Duo ensures very smooth and comfortable driving in all driving conditions supported by electric, serial and parallel driving modes. 

Being part of Magna’s modular and scalable building blocks, the mature common parts, including e.g., the shift system and park lock system, would be re-utilized. In addition, the usage of dog clutches generates even further package and cost benefits to our global customers.

Download Factsheet

Dedicated Hybrid Drive DHD Eco

DHD Eco – the next-generation hybrid drive

The DHD Eco is consequently designed for dominant electric operation. Therefore, the electric drive is the functional core and the 120 kW e-motor handles the most dynamic driving situations in hybrid mode. In turn, the combustion engine can be operated more consistently resulting in less fuel use and reduced GHG.

Furthermore, the e-motor handles launch and reverse driving. This is beneficial because e-motors can be controlled more exactly and precisely than typical clutches or torque converters. As a result, the DHD Eco offers better traction and launch acceleration. Stop-and-go operation is also more comfortable due to the absence of the clutch and shift operation.

Given its much-reduced mechanical complexity, the DHD Eco is the most cost-efficient plug-in hybrid drive on the market. Best-in-class efficiency and small packaging are further benefits. Its compactness even allows for B segment applications. It enables a new generation of plug-in hybrid drives, which allow for a new level of efficiency and performance in both electric and hybrid driving modes.

Scalable and modular building blocks

The DHD Eco with its electric drive components is part of the Magna kit of modular and scalable building blocks. These core components include e-motors, inverters, shift elements, and clutches, as well as the software itself. This allows for parameters like performance and range to adapt to real-world requirements in different vehicle segments and markets.

Download Factsheet

Efficient HEV and PHEV Technology Demonstrator with DHD Duo.

The technology demonstrator with Magna’s DHD Duo is an advanced HEV and PHEV solution based on a two e-motor architecture. It improves range and efficiency for high-volume passenger cars & SUVs with front-wheel drive.

Competitive advantage/differentiators

Very good acceleration performance due to the interaction of high-powered e-motor and a multi gear approach
Very smooth & comfortable driving in all driving conditions supported by electric, serial and parallel driving modes
Shifting without notice for the multi-speed architecture

Applications/benefits

Reuse of mature technologies & building blocks, ASIL C for e-motor and inverter 
140 kW high e-motor peak power
Impressive acceleration performance, comparable to a BEV

Download Factsheet

Powertrain Testing Services

Find here a detailed overview of our Testing Services.

Electrified Powertrain Systems by Magna

EtelligentEco

Connected PHEV Powertrain Solution with Full Drivability in Electric Mode

Learn more

EtelligentReach

Intelligent BEV Powertrain Solution with Maximum Range Efficiency and Drivability

Learn more

EtelligentCommand

Efficiency, Performance, and Control in one PHEV Solution

Learn more

EtelligentForce

Powerful BEV Drivetrain Solution for Passenger Trucks and Light Commercial Vehicles

Learn more

EtelligentTerrain

Advanced BEV Powertrain Solution for Sport and Light Utility Vehicles

Learn more

Video Gallery

Magna EtelligentDrive
The new language of Powertrains Watch Video EtelligentDrive

Picture of Dedicated Hybrid Drive DHD Eco — Dedicated Hybrid Drive DHD Eco

Picture of Dedicated Hybrid Drive DHD Plus — Dedicated Hybrid Drive DHD Plus

Picture of Highly Integrated eDrive Mid — Highly Integrated eDrive Mid+

Highly Integrated eDrive Low Cost Efficient

Picture of Dedicated Hybrid Drive DHD Duo — Learn more about the brand new DHD Duo solution
